Math Help - Express the area of the given surface as an interated double integral in polar coords

  1. #1
    Newbie
    Joined
    Nov 2012
    From
    Moms basement
    Posts
    5

    Express the area of the given surface as an interated double integral in polar coords

    Express the area of the given surface as an interated double integral in polar coordinates, and then find the surface area.

    A) the portion of the cone z=sqrt(x2+y2) That lies inside the cylinder x2+y2=2x

    First thing I did was transform x2+y2=2x into polar coords and got

    r2=2rcos(theta)

    r=2cos(theta)

    So I pretty much guessed that the integral goes from 0r2cos

    and also guessed that theta went from 0≤theta≤pi/2

    Not really sure how to prove that is goes from theta to pi/2 just assumed it was in quardrant 1.

    Now here is where I get confused,

    I then got the partials of z2=
    x2+y2 doing so I got
    dz/dx=rcostheta
    dz/dy=rsintheta

    I plug it into the formula for surface area which is sqrt[(dz/dx)2+ (dz/dy)2+1]da and im pretty sure this is incorrect.

    Thanks for the help

    Follow Math Help Forum on Facebook and Google+

  2. #2
    MHF Contributor
    Joined
    Sep 2012
    From
    Australia
    Posts
    3,619
    Thanks
    592

    Re: Express the area of the given surface as an interated double integral in polar co

    Hey mdhiggenz.

    x^2 + y^2 = 2x gives
    x^2 - 2x + y^2 = 0 or
    (x-y)^2 = 0

    I'm a bit unsure on how this is a cylinder: Usually a cylinder (axis-aligned) is x^2 + y^2 = r^2 with z varying if running along the z-axis.

    I might be misinterpreting your post though.
    Follow Math Help Forum on Facebook and Google+

  3. #3
    MHF Contributor
    Joined
    Oct 2008
    Posts
    1,034
    Thanks
    49

    Re: Express the area of the given surface as an interated double integral in polar co

    Quote Originally Posted by chiro View Post
    or
    (x-y)^2 = 0
    Whoops

    It's a circle radius one, centre (1,0). (So z can indeed vary giving a cylinder.)

    Use

    \displaystyle{ S\ =\ \int \int _D \ \sqrt{\big{(}\frac{\partial z}{\partial x}\big{)^2} + \big{(}\frac{\partial z}{\partial y}\big{)^2} + 1}\ \ dA}

    and afterwards convert,

    \displaystyle{ \int \int _D \ f(x,y)\ dA \ = \ \int \int _P f(r \cos \theta, r \sin \theta)\ r \ dr \ d \theta

    So for the partial wrt x,



    ... and similarly for y. Etc.

    And theta traces the top half of the circle as it goes from 0 to pi/2 and the bottom half as it carries on from there up to pi.


    Spoiler:

    \displaystyle \begin{align*} \sqrt{(\frac{\partial z}{\partial x})^2 + (\frac{\partial z}{\partial x})^2 + 1}\ &=\ \sqrt{\frac{x^2}{x^2 + y^2}\ +\ \frac{x^2}{x^2 + y^2} + 1} \\ \\ &=\ \sqrt{2} \end{align*}


    and,

    \displaystyle \begin{align*} S\ &=\ \int \int _D \ \sqrt{(\frac{\partial z}{\partial x})^2 + (\frac{\partial z}{\partial y})^2 + 1}\ dA \\ \\ &=\ \int \int _D \ \sqrt{2}\ dA \\ \\ &=\ \int \int _P \ \sqrt{2}\ r\ dr\ d\theta \\ \\ &=\ \int _0^{\pi} \int _0^{2 \cos \theta} \ \sqrt{2}\ r\ dr\ d\theta \end{align*}



    ... where (key in spoiler) ...

    Spoiler:


    ... is the chain rule. Straight continuous lines differentiate downwards (integrate up) with respect to the main variable or as indicated on the line, and the straight dashed line similarly but with respect to the dashed balloon expression (the inner function of the composite which is subject to the chain rule).





    __________________________________________________ ______________________________

    Don't integrate - balloontegrate!

    Balloon Calculus; standard integrals, derivatives and methods

    Balloon Calculus Drawing with LaTeX and Asymptote!
    Last edited by tom@ballooncalculus; November 5th 2012 at 04:58 AM.
