Math Help - Integration Question

  1. #1
    Member iPod's Avatar
    Joined
    Jul 2009
    Posts
    87

    Integration Question

    How do you integrate an equation in the form of

    \int \sqrt{x^2+a^2} dx
    Follow Math Help Forum on Facebook and Google+

  2. #2
    MHF Contributor
    Joined
    Aug 2007
    From
    USA
    Posts
    3,110
    Thanks
    2
    Various ways to go about it. A nice tangent substitution appears to be called for at first glance. What have you tried?
    Follow Math Help Forum on Facebook and Google+

  3. #3
    Member iPod's Avatar
    Joined
    Jul 2009
    Posts
    87
    I was actually using cos and sin, but i didnt get anywhere. I dont see how I can use tan
    Follow Math Help Forum on Facebook and Google+

  4. #4
    MHF Contributor
    Joined
    Aug 2007
    From
    USA
    Posts
    3,110
    Thanks
    2
    x = a\cdot\tan(\theta)?

    Of course, this might lead to [sec(x)]^3 and give you other problems, but it could result in something useful.
    Follow Math Help Forum on Facebook and Google+

  5. #5
    Newbie
    Joined
    Jun 2011
    From
    Right now it's the Earth, a strange place
    Posts
    17
    There are three ways, known to me, anyway.
    First you can substitute x=a \tan t.
    The second way is t=a \sinh t.

    And the third would be to rewrite this and use a special rule for integrals of this type:
    \int \frac{P_n(X)}{\sqrt{ax^2+bx+c}}\,dx=Q_{n-1}(x)\sqrt{ax^2+bx+c}+\lambda \int \frac{\,dx}{\sqrt{ax^2+bx+c}}
    Note that Q is a polynomial with unknown coefficients in X and is for one degree smaller than the degree of P. Lambda is also unknown so you actually have the same amount of unknowns as the degree of the polynomial. Although the last way might seem complicated I think it's quite easy so I'll demonstrate it and recommend to you that you try any other way (maybe the 2.?).

    Anyway, rewrite:
    \int \sqrt{x^2+a^2}\,dx=\int \frac{x^2+a^2}{\sqrt{x^2+a^2}}\,dx
    Now you actually have an integral of the type I mentioned. Set it equal to the right side:
    \int \frac{x^2+a^2}{\sqrt{x^2+a^2}}\,dx=(Ax+B)\sqrt{x^2  +a^2}+\lambda \int \frac{\,dx}{\sqrt{x^2+a^2}}
    Differentiate both sides, and solve for A, B, lambda:
    \frac{x^2+a^2}{\sqrt{x^2+a^2}}=A\sqrt{x^2+a^2}+(Ax  +B)\frac{x}{x^2+a^2}+\frac{\lambda }{x^2+a^2}
    x^2+a^2=Ax^2+Aa^2+Ax^2+Bx+\lambda
    So now we have:
    A=\frac{1}{2}
    B=0
    \lambda =\frac{a^2}{2}
    So our integral is actually equal to:
    \int \sqrt{a^2+x^2}\,dx=\frac{x}{2}\sqrt{x^2+a^2}+\frac  {a^2}{2}\int\frac{\,dx}{\sqrt{x^2+a^2}}
    \int \sqrt{a^2+x^2}\,dx=\frac{x}{2}\sqrt{x^2+a^2}+\frac  {a^2}{2} \ln(x+\sqrt{x^2+a^2})+C

    Well, that's my preferred way...
    Recommended substitution is the hyperbolic sine. Good luck.
    EDIT: Also noted you can do this with partial integration... I really love how many ways there are to integrals .
    Follow Math Help Forum on Facebook and Google+

  6. #6
    Super Member
    Joined
    Mar 2010
    Posts
    715
    Thanks
    2
    \begin{aligned}\displaystyle I & = \int(x)'\sqrt{a^2+x^2}\;{dx} \\ & = x\sqrt{a^2+x^2}-\int{x}\left(\sqrt{a^2+x^2}\right)'\;{dx}\\ & = x\sqrt{a^2+x^2}-\int \frac{x^2}{\sqrt{a^2+x^2}}\;{dx}\\ & = x\sqrt{a^2+x^2}-\int \frac{(a^2+x^2)-a^2}{\sqrt{a^2+x^2}}\;{dx}\\ & = x\sqrt{a^2+x^2}-\int \frac{a^2+x^2}{\sqrt{a^2+x^2}}\;{dx}+\int \frac{a^2}{\sqrt{a^2+x^2}}\;{dx}\\ & = x\sqrt{a^2+x^2}-\int {\sqrt{a^2+x^2}\;{dx}+\int \frac{a^2}{\sqrt{a^2+x^2}}\;{dx}\\ & = x\sqrt{a^2+x^2}-I+a^2\sinh^{-1}\left(\frac{x}{a}\right) \\ &  = \frac{x}{2}\sqrt{a^2+x^2}+\frac{a^2}{2}\sinh^{-1}\left(\frac{x}{a}\right)+k.  \end{aligned}
    Last edited by TheCoffeeMachine; June 8th 2011 at 02:45 PM.
    Follow Math Help Forum on Facebook and Google+

  7. #7
    MHF Contributor
    Joined
    Oct 2008
    Posts
    1,034
    Thanks
    49
    Quote Originally Posted by Croat View Post
    Recommended substitution is the hyperbolic sine. Good luck.
    Just in case a picture helps...

    First, noticing that

    \sqrt{a^2 + x^2}

    looks vaguely Pythagorean, we factor out the a^2...



    ... and, yes, we can see that substituting tan or else sinh for x/a would allow some kind of Pythag. Hang on, though - the reason the sub is useful is the chain rule...



    ... where (key in spoiler) ...

    Spoiler:


    ... is the chain rule. Straight continuous lines differentiate downwards (integrate up) with respect to the main variable (in this case x), and the straight dashed line similarly but with respect to the dashed balloon expression (the inner function of the composite which is subject to the chain rule).


    So we're going to integrate up the straight dashed line, i.e. with respect to the dashed balloon. But to make sure that doing that is the same as integrating the original with respect to x, we have to take account of the derivative of the inner function...



    ... just as the chain rule demands. Now, though, we can indeed remove the inner function (apply lubricant and turn carefully anti-clockwise, and the whole thing should come out)...



    ... and replace with sinh...



    ... which we had a hunch would be useful. And now we can see why - the hyperbolic counterpart of Pythag gives us cosh squared, which we can integrate with respect to theta.



    But then we know F (as soon as we've re-expressed the function of theta as a function of sinh x) and F is a function of the dashed balloon, and doesn't care what's inside. So we can remove the inner function (i.e. sinh) again, and replace the original (x/a).

    Spoiler:





    _________________________________________

    Don't integrate - balloontegrate!

    Balloon Calculus; standard integrals, derivatives and methods

    Balloon Calculus Drawing with LaTeX and Asymptote!
    Follow Math Help Forum on Facebook and Google+

  8. #8
    MHF Contributor
    Prove It's Avatar
    Joined
    Aug 2008
    Posts
    11,506
    Thanks
    1401
    Quote Originally Posted by iPod View Post
    How do you integrate an equation in the form of

    \int \sqrt{x^2+a^2} dx
    I would use a hyperbolic substitution, because \displaystyle \cosh^2{t} - \sinh^2{t} = 1 \implies \sinh^2{t} + 1 = \cosh^2{t}, and hyperbolic integrals are often easier than trigonometric...

    Anyway, after making the substitution \displaystyle x = a\sinh{t} \implies dx = a\cosh{t}\,dt the integral \displaystyle \int{\sqrt{x^2 + a^2}\,dx} becomes

    \displaystyle \begin{align*} \int{\sqrt{(a\sinh{t})^2 + a^2}\,a\cosh{t}\,dt} &= a\int{\sqrt{a^2\sinh^2{t} + a^2}\cosh{t}\,dt} \\ &= a\int{\sqrt{a^2(\sinh^2{t} + 1)}\,\cosh{t}\,dt} \\ &= a\int{a\sqrt{\cosh^2{t}}\,\cosh{t}\,dt} \\ &= a^2\int{\cosh{t}\,\cosh{t}\,dt} \\ &= a^2\int{\cosh^2{t}\,dt} \\ &= a^2\int{\frac{1}{2} + \frac{1}{2}\cosh{2t}\,dt} \\ &= a^2\left(\frac{1}{2}t + \frac{1}{4}\sinh{2t}\right) + C \\ &= a^2\left(\frac{1}{2}t + \frac{1}{2}\sinh{t}\sqrt{1 + \sinh^2{t}}\right) +C \\ &= a^2\left[\frac{1}{2}\sinh^{-1}{\left(\frac{x}{a}\right)} + \frac{1}{2}\left(\frac{x}{a}\right)\sqrt{1 + \left(\frac{x}{a}\right)^2}\right]+ C \\ &= a^2\left[\frac{1}{2}\sinh^{-1}{\left(\frac{x}{a}\right)} + \frac{x}{2a}\sqrt{\frac{a^2 + x^2}{a^2}}\right] + C \\ &= a^2\left[\frac{1}{2}\sinh^{-1}{\left(\frac{x}{a}\right)} + \frac{x\sqrt{a^2 + x^2}}{2a^2} \right]+ C \\ &= \frac{a^2}{2}\sinh^{-1}{\left(\frac{x}{a}\right)} + \frac{x\sqrt{a^2+ x^2}}{2} + C\end{align*}
    Follow Math Help Forum on Facebook and Google+

  9. #9
    Super Member
    Joined
    Mar 2010
    Posts
    715
    Thanks
    2
    Just for reference then, let's do this one too:

    \begin{aligned}\displaystyle I & = \int(x)'\sqrt{a^2-x^2}\;{dx} \\ & = x\sqrt{a^2-x^2}-\int{x}\left(\sqrt{a^2-x^2}\right)'\;{dx}\\ & = x\sqrt{a^2-x^2}+\int \frac{x^2}{\sqrt{a^2-x^2}}\;{dx}\\ & = x\sqrt{a^2-x^2}+\int \frac{a^2-(a^2-x^2)}{\sqrt{a^2-x^2}}\;{dx}\\ & =  x\sqrt{a^2-x^2}+\int \frac{a^2}{\sqrt{a^2-x^2}}\;{dx}-\int \frac{a^2-x^2}{\sqrt{a^2-x^2}}\;{dx}\\ & = x\sqrt{a^2-x^2}+a^2\int \frac{1}{\sqrt{a^2-x^2}}\;{dx}-\int \sqrt{a^2-x^2}\;{dx}\\ & = x\sqrt{a^2-x^2}+a^2\sin^{-1}\frac{x}{a}\;{dx}-I\\ & \end{aligned}

    \begin{aligned}\therefore \space & 2I = x\sqrt{a^2-x^2}+a^2\sin^{-1}\frac{x}{a}\;{dx}+k \\& \therefore I = \frac{1}{2}\left(x\sqrt{a^2-x^2}+a^2\sin^{-1}\frac{x}{a}\right)+k. \end{aligned}

    Isn't it wonderful that I can use the [tex] [/MATH] tags! Magic!
    Follow Math Help Forum on Facebook and Google+

  10. #10
    Member iPod's Avatar
    Joined
    Jul 2009
    Posts
    87
    Sorry, i had posted a reply earlier on but my internet had crashed. I had successfully managed to integrate it, using x=sinh(t)
    so i presume that integrating sqrt(x^2-a^2) requires the use of x=cosh(t) ?
    and what about sqrt(a^2-x^2)??
    Follow Math Help Forum on Facebook and Google+

  11. #11
    MHF Contributor
    Joined
    Aug 2007
    From
    USA
    Posts
    3,110
    Thanks
    2
    Quote Originally Posted by iPod View Post
    requires
    No. As I said in the first place, there are various ways to go about it.

    Quote Originally Posted by iPod View Post
    sqrt(a^2 - x^2)
    Why ask when you can explore? What do you think? Is this one easier or harder? Is hyperbolic trig warranted or maybe just x = a\cdot\sin(\theta)?
    Follow Math Help Forum on Facebook and Google+

  12. #12
    Member iPod's Avatar
    Joined
    Jul 2009
    Posts
    87
    ah true say.

    for \sqrt{a^2-x^2}
    i presume x=asin(t)
    would be a nice one since we get nice and easy trig stuff..
    Follow Math Help Forum on Facebook and Google+

  13. #13
    Member iPod's Avatar
    Joined
    Jul 2009
    Posts
    87
    ended up integrating a^2 cos^2(x), which is a^2*(1-2sin(t/2)).. worked out perfectly
    Follow Math Help Forum on Facebook and Google+

  14. #14
    MHF Contributor
    Joined
    Aug 2007
    From
    USA
    Posts
    3,110
    Thanks
    2
    Very good. Way to be up to it!
    Follow Math Help Forum on Facebook and Google+
